Built Tough for the Toughest Jobs

When it comes to heavy tipper trucks, the Tata Prima 3328.K stands out as the epitome of strength and efficiency. Designed to handle rugged terrain and heavy loads, this truck boasts a powerful engine that delivers exceptional horsepower and torque for smooth and efficient hauling.

Move ahead with the power to do more

  • <p>Engine</p>

    CUMMINS ISBe

    Engine

  • <p>Maximum Gradeability</p>

    35 %

    Maximum Gradeability

  • <p>Maximum Torque</p>

    970 Nm

    Maximum Torque

  • Maximum Torque

    6700 cc

    Maximum Torque

PRIMA 3328.K
PRIMA 3328.K

PRIMA 3328.K

The Tata Motors Prima 3328.K is a rugged and efficient tipper truck that is powered by the reliable CUMMINS ISBe, a water-cooled, direct injection, turbocharged, after-cooled Diesel engine. It delivers a maximum power output of 266 BHP at 2500 rpm and a maximum torque of 970 Nm. This truck is engineered to handle the most demanding tasks, providing faster turnaround while reducing maintenance costs.

The ZF 9F + 1 R gearbox ensures effortless gear shifts and smooth power transmission, and a full air dual circuit S Cam braking system offers enhanced control and safety during both loaded and unloaded operations. At the front, the truck features a Parabolic Leaf Spring, ensuring excellent ride comfort and stability during operation. At the rear, the truck is equipped with a two-spring balance beam bogie with semi-elliptic multi-rubber mounted torque rods and a V-Rod, enhancing load-carrying capacity and minimizing vibrations, even during heavy-duty operations.

Water Cooled, Direct injection, Turbocharged After Cooled Diesel engine
266 BHP Maximum Power
Hydraulic Power Steering
ZF 9F + 1 R Gearbox

The truck also boasts a host of premium features, including an Ergonomic World Class Prima Cabin, providing the operator with unparalleled comfort and reducing driver fatigue during long hauls. The driver seat is a Adjustable Bucket Seat with Fore Aft + Recliner + Height Adjustment, integrated head restraint, and a tilt and telescopic steering wheel, ensuring a customizable driving position for maximum convenience.

Contact Us

Features designed for performance and profits

Flat Torque Curve

Advantage

Lesser Gear Shift

Benefit

Constant Torque for Wider RPM Range, High Fuel Economy

Reliable aggregates e.g, Cummins Engine, ZF Gear Box, Proven and time Tested TATA RA 109 rear Axle

Advantage

World Class Technology

Benefit

Reliabiility

Better Grade Restartibility

Advantage

High Traction

Benefit

Suited for Tough Road conditions

Ergonomic World class Prima Cabin, Driver seat - Mechanical static adjustable bucket seat with Fore aft + recliner + height adjustment with integrated head restraint, tilt and telecsopic steering wheel

Advantage

Lesser Fatigue for Driver

Benefit

more no. of trips Trips

Availaibility of Service Parts

Advantage

Ease of Servicability

Benefit

High Uptime

Features such as Engine Exhaust Brake, 2 Stage Air Filter

Advantage

Value Added Comfort features

Benefit

More trips high profitability

Bogie Suspension

Advantage

Higher load carrying capacity

Benefit

Higher Profit & Improved Tyre & Axle life

01
PRIMA 3328.K

PRIMA 3328.K specifications

  • Engine

    CUMMINS ISBe 270 -Water cooled, direct injection, turbocharged, after cooled Diesel engine

  • Engine Capacity

    6700 cc

  • Max Engine Output

    266 BHP @ 2500 rpm

  • Max Speed

    87

  • Emission

    E-III

  • Torque

    970 Nm @ 1500 rpm

  • Gradeability

    35%

  • Gear Box

    ZF, 9F + 1 R

  • Clutch

    430

  • Steering System

    Hydraulic Power Steering

  • Brakes

    Full Air Dual circuit - S Cam

  • Suspension - Front

    Parabolic leaf spring

  • Suspension - Rear

    Two spring balance beam Bogie with semi elliptic multi rubber Mounted Torque Rods & V-rod

  • Tyre Size

    11R22.5

  • Length

    7312

  • Width

    2515

  • Height

    3070 mm

  • Wheelbase

    3950 mm

  • Ground Clearance

    229 mm

  • Turning Circle Radius

    8385 mm

  • GVW

    25000 kgs

  • Kerb Weight

    8855

  • Max Permissible FAW

    6000

  • Max Permissible RAW

    19000

  • Fuel Tank Capacity

    260

  • Cabin Ventilation

    AC

  • Body Option

    16 Cum
