Unleash Urban
Payload Potential

Seamlessly manoeuvre through crowded streets, efficiently manage your cargo, and keep your operations running smoothly with the powerful Ultra T16. With its smart design and reliable performance, this truck is more than just a commercial vehicle.

Move ahead with the power to do more

  • <p>Emission Compliant Standard</p>

    Euro IV

    Emission Compliant Standard

  • <p>Engine Capacity</p>

    5005 cc

    Engine Capacity

  • <p>Max Torque</p>

    590 Nm

    Max Torque

  • <p>Gradeability</p>

    25%

    Gradeability

ULTRA T.16
ULTRA T.16

ULTRA T.16

Unleash the power of efficiency and reliability with the Ultra T.16, a medium commercial cargo truck designed to redefine your cargo transportation experience. Equipped with a robust Compression Ignition Diesel Engine, this powerhouse delivers an impressive maximum power output of 180 PS at 2400 rpm, coupled with a maximum torque of 590 Nm, ensuring that your cargo is carried effortlessly across every mile.

This truck features a cutting-edge Tata G750 Synchromesh 6F + 1R gearbox, guaranteeing smooth gear transitions and optimal performance. Safety takes precedence with the advanced Dual Circuit Full Air S-cam Brakes + ABS system, providing impeccable stopping power and instilling confidence in every braking manoeuvre. Thanks to the innovative suspension system that seamlessly combines parabolic and semi-elliptical leaf springs, it ensures a comfortable, stable ride, safeguarding your precious cargo in every journey.

3.3LNGD09 Engine
180 Ps Maximum Power
Tata G750 6F+1R Gearbox
Dual Circuit Full Air S-Cam Brake System With ABS

Take on every terrain with an impressive gradeability of 25%. Equipped with durable, lasting aggregates and proven engine, the Ultra T16 is built to take on challenges head-on, making it the ultimate companion for navigating diverse terrains with finesse.

Contact Us

Features designed for performance and profits

3.3L NG Common Rail TCIC Euro-IV

Advantage

1. Most Efficient Engine with 3300 cc capacity
2. Higher Mileage
3. High 155Ps Power
4. Common Rail FIP with Advanced Engine Management System
5. Solenoid injectors for precise fuel delivery, superior reliability

Benefit

Move Savings due to lesser fuel consumption, Higher speed resulting in better turn around capacity

High Torque of 450Nm @ 1500-2000 rpm

Advantage

1. Best in class torque even at low rpm
2. Higher pulling Capacity

Benefit

Ability to pull more load easily at the low rpm ranges, Relatively less gear shifting, Better Acceleration

Dual circuit full Air S-cam Brakes + ABS

Advantage

1. Efficient and effective braking
2. Better Braking Distance
3. Decreased Response Time
4. Lesser Maintenance

Benefit

Effective and Safer braking compared to Hydraulic and air over hydraulic brakes, critical in high speed operations.

Tata G550 (6F+1R) Synchromesh Gear box with Cable shift mechanism

Advantage

1. Low Vibration
2. Improved mileage
3. Ease of Operations across terrains

Benefit

Reduced gear shifting efforts, better life of gearbox

Parabolic and semi elliptical leaf spring

Advantage

Lower maintainance cost because of less greasing,

Benefit

Better load carrying  capacity and higher driving comfort due to lower vibrations

01
ULTRA T.16

ULTRA T.16 specifications

  • Engine

    3.3LNGD09

  • Engine Type

    Compression ignition diesel engine

  • Body Type

    Cab-Chassis

  • Engine Capacity

    5005cc

  • Max Engine Output

    180 Ps @2400 rpm

  • No of Cylinders

    4 INLINE

  • Cylinders / Displacement

    4 cylinder, 5005 cc

  • Max Speed

    100 kmph

  • Emission

    EuroIV

  • Torque

    590Nm @ 1000-2000rpm

  • Gradeability

    25%

  • Transmission Model

    Manual

  • No of Gears

    6 Forward +1 Reverse

  • Gear Box

    Tata GBS 750 Synchromesh

  • FGR

    9.19

  • Clutch

    Single plate dry friction type, booster assisted

  • Clutch Lining Outside Diameter

    352 mm

  • Steering System

    Integrated Hydraulic Power

  • Brakes

    Dual circuit full Air S-cam Brakes + ABS

  • Brake - Front

    Full Air S-Cam with Auto slack adjuster

  • Brake - Rear

    Full Air S-Cam with Auto slack adjuster

  • Brake Drum Diameter

    410 mm

  • Suspension

    Parabolic and semi elliptical leaf spring

  • Suspension - Front

    Parabolic Springs

  • Suspension - Rear

    Semi elliptical leaf spring with auxilary springs

  • Antiroll Bar

    YES

  • No of Tyres

    Front: 2, Rear:4 and Spare: 1

  • Tyre Size

    275/80R22.5

  • Wheel Rims

    8.25 x 22.5

  • Size & Ply rating

    275/80R22.5

  • Axle - Front

    Extra Heavy duty Forged I beam, Reverse Elliot type

  • Axle - Rear

    Single reduction hypoid gears, fully floating axle shafts

  • Axle Final ratio

    4.11

  • Frame

    Ladder Type Straight Frame

  • Frame Depth

    250 mm

  • Frame Width

    854

  • Length

    9400

  • Width

    2440

  • Height

    2630

  • Wheelbase

    5300

  • Over Hang - Front

    1355

  • Over Hang - Rear

    2745

  • Turning Circle Radius

    8.5 mm

  • Turning Circle Diameter

    18.8

  • Track Front

    1984

  • Track Rear

    1813

  • Angle of Departure

    10 deg

  • GVW

    16190

  • Kerb Weight

    5150

  • Max Permissible FAW

    5990

  • Max Permissible RAW

    10200

  • Payload

    11040

  • Fuel Tank Capacity

    160

  • Cabin

    Ultra Wide Cabin

  • Cabin Ventilation

    HVAC

  • Battery

    24V, 2 X 100AH

  • Vehicle Drive

    LHD

  • Alternator

    24V, 2 X 100AH

  • Seats

    Driver : BUCKET TYPE + BENCH SEAT FOR 2 CO-PASSENGERS.
